C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Page 4-48 Publication No. 150-041118
Section 4 – Electrical Installation Rev A
Sep 2001
(2) C-5000 Transceiver (RT-9600(F)/7200) Connector P50X (P501, P502, or P503)
PIN SIGNAL NAME PIN SIGNAL NAME
1 TONE SELECT C 32 4 MHZ
2 TX POWER ANNUNCIATE 33 PTT
3 0.08 MHZ 34 0.01 MHZ
4 20 MHZ 35 0.005 MHZ
5 80 MHZ 36 GUARD TONE ENABLE
6 TONE E 37 RT7200: 40 MHZ, RT9600(F): .0025
MHZ, RT9600F w/DVP/DES: 40 MHz
7 SPARE #2 38 RT7200, RT9600(F):CIPHER/PLAIN
RT9600F w/DVP/DES: CH PVT/STD
8 ON/OFF 39 RT7200, RT9600(F): TX RT9600F
w/DVP/DES: RAD PTT
9 RT7200: 40 MHZ, RT9600(F): .0025
MHZ, RT960OF w/DVP/DES:
.002MHZ
40 PLAIN/CIPHER
10 2 MHZ 41 AUDIO LO
11 MIC HI 42 MAIN VOLUME
12 TONE SELECT A 43 TONE SELECT B
13 MAIN AUDIO INHIBIT 44 0.04 MHZ
14 TX PWR SELECT 45 EXTERNAL CTCSS ENCODE IN
15 CHN MEMORY DISCRETE NO. 2 46 DF DISABLE
16 CHN MEMORY DISCRETE NO. 3 47 TAKE CONTROL
17 CHN MEMORY DISCRETE NO. 4 48 GUARD SQUELCH ANNUNCIATE
18 SPARE #3 49 0.1 MHZ
19 GUARD SELECT 50 GUARD VOLUME
20 ZEROIZE 51 800 MHZ
21 UNSQUELCHED MAIN AUDIO 52 0.4 MHZ
22 SHIELD 53 0.2 MHz
23 TONE SELECT D 54 EXTERNAL GUARD AUDIO INHIBIT
24 SPARE #1 55 0.8 MHZ
25 SQUELCH DISABLE 56 CHN MEMORY DISCRETE NO. 1
26 10 MHZ 57 0.02 MHz
27 100 MHZ 58 MAIN SQUELCH ANNUNCIATE
28 400 MHZ 59 CHN MEM DISCRETE NO. 5
29 TONE D 60 UNSQUELCHED GUARD AUDIO
30 1 MHz 61 AUDIO HI
31 8 MHZ 62 CONTROL GROUND 22 AWG
Table 4-6. C-5000 Transceiver (RT-9600(F)/7200) Connector P50X (P501, P502, or P503)
