Xantrex Freedom X 2000 User Manual

AC and DC Panel
975-0822-01-01 7
Item Description
7 DC terminal opening for routing (+) positive DC cable.
8 LED alert indicator for reverse DC polarity.
9 AC output terminal opening for routing AC output wiring.
10 AC input terminal opening for routing AC input wiring.
11
cReserved for future use. AC cover.
12
Mounting flanges on both sides allow you to mount the
inverter permanently on the interior deck or on a wall.
13
Ventilation grille (openings) must not be obstructed for
the proper operation of the cooling fan and inverter. When
the inverter is mounted, the ventilation grille must not point
up or down.
Cooling fans turn on when the internal temperature
reaches a set point temperature.
14
cReserved for future use. Supplementary protector
with reset button.
15
ACOut Neutral-to-Earth Bond. See "AC Output Neutral
Bonding Option (Earth Relay Function)" on page17 for
more information.
WARNING
ELECTRICAL SHOCK HAZARD
n Use a torque screwdriver to tighten the bolt on the DC
earth lug to a torque of 2.6 N-m of force.
n Apply an anti-corrosion compound to the copper wire prior
to connecting to the DC earth lug.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.

Xantrex Freedom X 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Efficiency	90%
Waveform	Pure Sine Wave
Protections	Overload, Over Temperature, Short Circuit
