Introduction
1–2 975-0402-01-01
This guide for use by qualified installers only
Standard and Protection Features
The Truecharge™ 2 Battery Charger provides the following standard
features:
•three
1
full current rated outputs
• battery monitoring functions while in float mode or rest
mode
• correct charging voltage for your batteries when
connected to almost any single phase AC power outlet in
the world
• low electromagnetic interference (EMI)
• automatic charge resumption after AC power interruption
• programmable custom charge sequence
2
• fully discharged battery charging
3
• an optional remote panel
4
which can be mounted up to
15 m (50 ft) away for remote control and monitoring.
• an optional battery temperature sensor
5
(BTS) provides
battery temperature voltage compensation from -25 to
70 °C (-13 to 158 °F)
1.Model TC1012 has one output and model TC1512 has two outputs. All other models
have three outputs. Each output (for models with 2 or 3 outputs) can charge different bat-
teries that either have the same chemistry or can tolerate the same charge sequence.
2.The charger can be programmed with custom charge setpoints using PC interface. This
programming can only be done using a special configuration tool operated by Xantrex or a
designated OEM.
3.The charger can initiate charging a non-damaged but zero voltage battery.
4.Part number: 808-8040-00
5.Part number: 808-0232-01
TC2 Series BattChg Install Guide.book Page 2 Monday, June 30, 2008 3:18 PM
