Installation
2–22 975-0402-01-01
This guide for use by qualified installers only
5. Install the DC chassis ground (earth) from the ground
stud on the Truecharge™ 2 Battery Charger to the engine
bus or DC ground bus (Figure 2-4, item 15). Use a flat
washer, a lock washer and a nut (included in the
installation kit) to secure the connection.
Tighten the nuts to 2.3 N-m (20 lb-in.) torque and test
that the wire is secure. Do not over-tighten as this may
result in damage to the charger.
6. Connect any optional accessories. See “Installing
Optional Accessories” on page 2–24.
7. Secure cables in place using tie-wraps, P-clamps or cable
straps according to electrical codes. Coil and tie any BTS
or remote panel extension cable.
8. The DC breakers may be closed at this time.
Final AC Connections
To make the final AC connections:
1. Complete the installation by routing the AC cable to the
AC source.
2. Connect the AC cable to the AC disconnect breaker and
ground in accordance with the color codes on page 2–16.
3. Secure cables in place using tie-wraps, P-clamps or cable
straps according to electrical codes.
4. The AC mains may be applied at this time by closing the
breaker.
TC2 Series BattChg Install Guide.book Page 22 Monday, June 30, 2008 3:18 PM
