Specifications
A–6 975-0402-01-01
This guide for use by qualified installers only
DC Output Specifications
Temperature Specifications
DC output voltage range including
dead battery charging voltage
12 V units: 0 – 15.5 Vdc
24 V units: 0 – 31 Vdc
Maximum equalization voltage
(no BTS installed)
12 V units: 16 Vdc
24 V units: 32 Vdc
Voltage accuracy (no load) 12 V units: ±0.1 Vdc at 14.4 Vdc @ 25 °C
(77 °F)
24 V units: ±0.2 Vdc at 28.8 Vdc @ 25 °C
(77 °F)
Voltage regulation Uncompensated load voltage regulation <
0.1Vdc drop from 0 Amps to rated current
output at charger output terminals (adds in
series with recommended 3% limit for
user's battery cable voltage drop).
Nominal ambient 25 °C (77 °F)
Operating range
(full performance) –20 – 50 °C (–4 – 122 °F)
Current de-rating (above 50 °C
ambient temperature)
upto 80% derating Imax
(50 – 65 °C) (122 – 149 °F)
Storage –40 to 80 °C (–40 to 176 °F)
Humidity 5 – 95%, RH non-condensing
TC2 Series BattChg Install Guide.book Page 6 Monday, June 30, 2008 3:18 PM
