Installation
2–4 975-0402-01-01
This guide for use by qualified installers only
Tools and Materials
To mount and connect the Truecharge™ 2 Battery
Charger you need the following tools:
• 10 mm socket wrench and extension for the DC terminals
and ground stud
• Phillips screwdriver for removing and re-securing the AC
and DC wiring compartment covers
• power drill/screwdriver
• drill bit for pilot holes for mounting screws (if using #6
mounting screws, use 1/16 drill)
• wire stripper
• manufacturer's recommended crimp tool for any crimp
terminals that are being used
You need the following materials:
• 3 conductor AC input wiring
Use the information in “Planning AC Wiring” on page 2–
15 and your local electrical codes to determine the
correct wire and breaker or fuse.
• AC cable strain relief (if the one included is not
compliant with your local electrical code requirements)
• appropriately sized DC cables for each battery, with
suitable connectors at the battery end
• appropriately sized DC chassis ground (earth) with
suitable connectors
• ring terminals to fit 6 mm (1/4 in.) studs at the charger
end (Marine grade hardware is recommended).
• DC fused disconnect or properly rated circuit breaker for
each battery bank
• mounting screws, M3 or #6 marine grade, corrosion
resistant (4 pieces) (Length dependent on mounting
surface).
