Preparing for Installation
975-0402-01-01 2–3
This guide for use by qualified installers only
1 AC mains source protected by correct size and type of branch rated
circuit breaker
2 AC input wiring compartment
3 DC negative cable
4 DC positive cables
5 DC circuit breakers or DC fused disconnects
6 Battery or battery bank
7 Engine ground bus or DC negative bus
8 Remote panel
(optional accessory part number: 808-8040-00)
9 Battery temperature sensor
(optional accessory part number: 808-0232-01)
10 DC chassis ground (earth)
