Electrical Specifications
975-0402-01-01 A–3
This guide for use by qualified installers only
Electrical Specifications
Number of isolated
battery bank outputs
TC1012:
1 output
TC1512:
2 separated outputs
TC2012, TC3012, TC4012, TC5012, TC6012,
TC1524, TC2024, TC3024, TC5024:
3 separated outputs
Nominal battery voltage 12 V units:12 Vdc
24 V units:24 Vdc
Normal operating output
range
12 V units: 0 – 16 Vdc
24 V units: 0 – 32 Vdc
Nominal operating AC
input voltage
110 – 250 Vac
Maximum DC output
current (total)
TC1012: 10 ±10% A
TC1512: 15 ±10% A
TC2012: 20 ±10% A
TC3012: 30 ±10% A
TC4012: 40 ±10% A
TC5012: 50 ±10% A
TC6012: 60 ±10% A
TC1524: 15 ±10% A
TC2024: 20 ±10% A
TC3024: 30 ±10% A
TC5024: 50 ±10% A
Absorption voltage:
±0.1 V for 12 V units
±0.2 V for 24 V units
12 V units 24 V units
25°C (77°F) 25°C (77°F)
Flooded 14.4 28.8
GEL 14.2 28.4
AGM 14.3 28.6
Lead-calcium 15.5 31.0
