Specifications
A–2 975-0402-01-01
This guide for use by qualified installers only
Physical Specifications
Base Unit
Dimensions:
L × W × H
TC1012, TC1512:
200 × 170 × 70mm (7.87 × 6.70 × 2.76 in.)
TC2012, TC3012, TC4012:
250 × 170 × 70mm (9.84 × 6.70 × 2.76 in.)
TC5012, TC6012:
350 × 170 × 70mm (13.78 × 6.70 × 2.76 in.)
TC1524, TC2024:
250 × 170 × 70mm (9.84 × 6.70 × 2.76 in.)
TC3024, TC5024:
300 × 210 × 125mm (11.81 × 8.27 × 4.92 in.)
Weight TC1012, TC1512: 2.0 kg (4.4 lbs)
TC2012, TC3012, TC4012: 2.2 kg (4.8 lbs)
TC5012, TC6012: 4.5 kg (9.9 lbs)
TC1524, TC2024: 2.2 kg (4.8 lbs)
TC3024, TC5024: 5.0 kg (11.0 lbs)
AC input
connections
Two color-coded No. 14 AWG wires (L, N) and one
No. 14 AWG (G) minimum 152 mm (6 in.) long in a separate
AC wiring enclosure with 21.3 mm (0.84 in.) hole provision for
connection of a ½ inch North American "trade size" cable clamp
(included).
DC output
connections
TC1012:
Two M6 studs (1 positive and 1 common negative) for battery
cable ring terminals and one M6 mm DC equipment ground
TC1512:
Three M6 studs (2 positives and 1 common negative) for battery
cable ring terminals and one M6 mm DC equipment ground
TC2012, TC3012, TC4012, TC5012, TC6012, TC1524,
TC2024, TC3024, TC5024:
Four M6 studs (3 positives and 1 common negative) for battery
cable ring terminals and one M6 mm DC equipment ground
TC2 Series BattChg Install Guide.book Page 2 Monday, June 30, 2008 3:18 PM
