Installation
2–12 975-0402-01-01
This guide for use by qualified installers only
Installing the Truecharge™ 2 Battery
Charger
Installation Sequence
To make charger installation quick and easy, Xantrex
recommends that the installation tasks be performed in the
following sequence:
1. Select charger mounting position and plan AC and DC
cable routing.
2. Plan DC cable runs and install fuses or breakers (page 2–
13).
3. Plan the AC connections at the charger (page 2–15).
4. Mount the charger in position (page 2–18).
5. Make the final DC (see page 2–19) and then AC cable
connections (including earth grounds) (page 2–19).
6. Apply DC to the charge by closing the DC breakers or
disconnects (page 2–23).
7. Apply mains AC to the charger by closing the AC input
breaker.
WARNING: Shock and Energy Hazards
Be sure to read the safety guidelines and pay attention to all
cautions and warnings throughout the installation procedure. The
installer is responsible for ensuring compliance with the installation
codes for your particular application.
Disconnect all sources of AC and DC power before proceeding.
