Introduction
1–4 975-0402-01-01
This guide for use by qualified installers only
Truecharge™ 2 Battery Charger
This section describes the different parts of the Truecharge™
2 Battery Charger.
Figure 1-1
Truecharge™ 2 Battery Charger
Item Description
1 Onboard control and status display panel or simply
onboard display (see “Rear Panel” on page 1–6 for
more information) for controlling the Truecharge™ 2
Battery Charger settings and for monitoring charger
status and charging current.
2 Mounting flanges are used to permanently install the
product.
3 DC wiring compartment cover protects the DC
terminals, as well as the communication and BTS ports.
Remove and replace when installing cables.
1
2
6
4
3
5
