Truecharge™ 2 Battery Charger
975-0402-01-01 1–5
This guide for use by qualified installers only
4 Fuse access panel cover provides access to the DC fuse
in the event of an accidental reverse polarity installation.
5 AC wiring compartment cover provides the installer
with easy access to the AC wiring compartment, to
allow for a trouble free installation. Remove and replace
when installing the product.
6 DC ground stud for connecting the charger’s chassis to
ground.
Item Description
