Rear Panel
975-0402-01-01 1–7
This guide for use by qualified installers only
7 Air intake vent - located inside is the fan assembly
8 AC wiring - line, neutral, and ground input wires
Important:
When installing only a single bank (or one
battery) for Truecharge™ 2 Battery Chargers that have
multiple outputs, positive bank 1 must be utilized. Bypassing
bank 1 and using any of the other banks (bank 2 or bank 3)
may render the charger to function improperly.
Item Description
