Remote Operation
Remote Analog Operation
Release 3.0 111
Next select analog programming as the remote control interface.
Your options are
• Analog V & I - voltage and current programmed via the analog interface
• Analog V - voltage programmed via the analog interface; current set via front panel
• Analog I - current programmed via the analog interface; voltage set via front panel
Press the LCL/RMT button to begin remote operation via the analog interface.
SCPI
To select which setpoints to control via analog programming lines, use the
command:
SYST:REM:SOUR {AVOL|ACUR|AVC}
Where
• AVOL (Analog VOLtage) selects only voltage to be programmed via the analog
programming lines
• ACUR (Analog CURrent) selects only current to be programmed via the analog
programming lines
• AVC (Analog Voltage and Current) selects voltage and current to be programmed
via the analog programming lines
To select the voltage level:
SYST:COMM:APR:LEV {5|10}
Where
“5” is the 0-5V range, and
“10” is the 0-10V range
To put the unit into remote control:
SYST:REM:STAT REM
Step # Do This You Will See
1 ERROR MSGS
2 4 times REMOTE SELECT
3 RS-232
4 or
Select desired option.
Analog V&I,
Analog V, or
Analog I
5
Setting is saved.
MENU

ENTER


ENTER
