Xantrex XDC User Manual

Remote Operation
SCPI Commands for Digital Interfaces
148 Operating Manual for XDC Series Power Supply
Table 4.13 Remote CONtrol Sub-Register
Current SHare Sub-Register
This register shows the state of the current share configuration, which can either be
set through the front panel Current Share Config menu, or through the SCPI
command SOURce:COMBine:CSHare:MODE.
Table 4.14 Current SHare Sub-Register
Bit Bit Weight Bit Name Description
0 1 Analog
Control
Voltage
The Voltage Setpoint is under control of the
Analog Programming Interface.
1 2 Analog
Control
Current
The Current Setpoint is under control of the
Analog Programming interface.
2 4 GPIB
CONtrol
The power supply is under Remote CONtrol via
the GPIB interface.
3 8 GPIB
CONtrol
with LLO
The power supply is under Remote Control via
the GPIB interface, with local controls locked out.
4 16 RS-232
CONtrol
The power supply is under Remote CONtrol via
the RS-232 interface.
5 32 RS-232
Control with
LLO
The power supply is under Remote CONtTrol via
the RS-232 interface, with local controls locked
out.
6 64 Multi-chann
el CONtrol
The power supply is under Remote CONtrol via
the Multi-channel Programming interface.
7 128 Multi-chann
el Control
with LLO
The power supply is under Remote CONtrol via
the Multi-channel Programming interface, with
local controls locked out.
Bit Bit Weight Bit Name Description
0 1 MASTer The power supply is configured to be a Current
Share Master.
1 2 SLAVe The power supply is configured to be a Current
Share Slave.
