Operation
Power Supply Operation
64 Operating Manual for XDC Series Power Supply
Power Supply Operation
This section describes how to configure and operate the power supply.
Set Voltage The VOLTAGE key allows you to set and view the DC voltage output setpoint.
Set Current The CURRENT key allows you to set and view the DC current output setpoint.
Step # Do This You Will See
1 Set #####V
2
Use the numeric keypad, Voltage
knob, or arrow keys to enter a value
(0–103% of rated voltage).
3 This saves the setting and enables
the new voltage setpoint.
VOLTAGE
ENTER
Step # Do This You Will See
1 Set #####A
2
Use the numeric keypad, Current
knob, or arrow keys to enter a value
(0–103% of rated current).
3 This saves the setting and enables
the new current setpoint.
CURRENT
ENTER
