Operation
Power Supply Operation
Release 3.0 79
Recall
Settings
After you have saved one or more settings, you can press RECALL to retrieve them
from the power supply’s non-volatile memory or to run an auto-sequence program.
(You can also recall stored settings through your Power ON configuration. See
“Configure Power ON Settings” on page 84.)
To retrieve a setting using RECALL:
Four options are available from the Recall memory:
1. Last Setting: Returns the setpoints to values stored before power was turned off.
2. User Settings: Returns the setpoints to one of ten possible saved values.
3. Factory Preset: Returns the setpoints to the original out-of-the-box values.
4. Auto Sequence: Returns control of the setpoints to one of ten possible saved
programs. (For further information, see “Program Auto Sequence” on page 87.)
To access these options, press RECALL repeatedly until the correct option appears,
or press the arrow keys. Pressing RECALL lets you scroll through the options in the
direction listed above. Pressing the arrow keys lets you cycle through the options in
either direction.
To restore the last setting:
Step # Do This You Will See
1 Last Setting
2
User Settings
3 User Set 1
1
1. If you want a different setting besides Set 1, use the arrow keys or numeric keypad.
4
This setting is retrieved from memory,
the power supply’s output changes to
match the setting, and the display
returns to its default operating mode.
Step # Do This You Will See
1 Press once. Last Settings
2 Press to restore last
setting.
RECALL
RECALL
ENTER
ENTER
RECALL
ENTER
To Next Page
