Xantrex XDC User Manual

GPIB
Protocol Specifications
224 Operating Manual for XDC Series Power Supply
Protocol Specifications
Multiline
Control
Functions
IEEE 488.2 (Section 5) requires specific Device Interface Functions.
Table D.1Multiline Control Functions
Interface
Functions
IEEE 488.1 (Section 2).
Table D.2Interface Functions
Function Mnemonic Description Functions Subset
Source
Handshake
SH1 Complete capability SIDS, SGNS, SDYS, STRS,
SWNS, SIWS
Acceptor
Handshake
AH1 Complete capability AIDS, ANRS, ACRS, ACDS,
AWNS
Talker T6 Includes serial poll TIDS, TADS, TACS, SPAS,
SPIS, SPMS, TPIS, TPAS
Listener L4 LIDS, LADS, LACS, LPIS,
LPAS
Function Mnemonic Description Functions Subset
Device Clear DC1 Complete capability DCIS, DCAS
Device Trigger DT1 Complete capability DTIS, DTAS
Drivers E2 Tri state drivers where
selectable
Parallel Poll PP1 Parallel Poll
Remote/Local RL1 Complete capability LOCS, LWLS, REMS, RWLS
Service
Request
SR1 Complete capability NPRS, SQRS, APRS
Controller C0 Device does not act as a
controller
