Xerox B1022 User Manual

The Saved window appears.
8. Press the green Start button.
CCooppyyiinngg CCoovveerrss
You can copy the first and last pages of your copy job on speciality paper, such as colored or
heavyweight paper. The printer selects the cover paper from a different tray.
Note: Including covers option is not available with Auto Tray.
To copy covers:
1. Place the cover of the original document on the document glass.
2. If necessary, load the paper for the document into the appropriate paper tray.
3. Load the cover paper into a different tray.
4. At the printer control panel, press the Copy button.
5. Press the Menu button.
6. On the Copy Features screen, select the Covers option.
7. Press the OK button.
8. For Covers Position, select an option:
• Off: This is the default option.
• Front & Back: This option sets the Covers Position at both the front and back of the original
document.
• Front Only: This option sets the Covers Position at the front of the original document only.
• Back Only: This option sets the Covers Position at the back of the original document only.
9. Press OK.
10. For Print on Cover, select an option:
• Blank Cover: This option does not copy a cover to either side of the paper.
• Print on Side 1 only: This option copies a cover to only one side of the paper.
• Print on Both Sides: This option copies a cover to both sides of the paper.
11. Press OK.
12. For Covers Tray, select an option.
• Bypass Tray: This option copies the cover to paper loaded in the Bypass Tray.
• Tray 1: This option copies the cover to paper loaded in Tray 1.
Note: A Tray 2 option is listed when a printer has an optional Tray 2.
13. To save the changes, press OK.
The Saved screen appears.
14. Press the green Start button.
54
Xerox
®
B1022 Multifunction Printer
User Guide
Using the Services

Xerox B1022 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Watermark printing	Yes
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	11 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.8 s
Copy speed (black, normal quality, A4)	22 cpm
Faxing	No
Scan to	E-mail, FTP, PC, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIFF
Document formats supported	PDF
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	600 sheets
Sound power level (standby)	30 dB
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1100 W
Power consumption (off)	2 W
Power consumption (ready)	80 W
Power consumption (sleep)	1 W
Power consumption (average operating)	550 W
Energy Star Typical Electricity Consumption (TEC)	1.2 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black, White
Market positioning	Business
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32000 g
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PostScript
Paper tray media types	Bond paper, Heavy paper, Letterhead, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm), Tabloid (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	2500 pages

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
