• After cleaning the scanner, do a test scan and view the final image file. Do not perform a shading
adjustment until after you clean the scanner and test scan. A shading adjustment performed before cleaning
the scanner may result in degraded image quality.
• Have the Shading Paper, provided with your scanner, ready as the software will tell you when to insert it into
the scanner.
• Make sure the Shading Paper is in-like new condition.
The Shading Paper should be kept in the plastic bag between the stiff cardboard when not in use.
If the Shading Paper is creased, torn, soiled, crumpled or dirty, the image quality will degrade instead of
improve after performing the Shading Adjustment.
If your Shading Paper is not in like-new condition, please order a replacement at www.xeroxscanners.com in
the Parts & Accessories page for your scanner.
• Change the front and back background reference plates to white. Please refer to the instructions in section
Changing the Background Color on page 155. During the shading adjustment you will need to change the
background color to white then to black. After the shading adjustment is complete, choose the color you
want the background to be.
To complete a shading adjustment:
1. Open the scanner User Utility application.
2. On the main window click on the User Shading... button.
3. Click on Start Shading to begin the shading adjustment. The shading adjustment utility will guide you
through the rest of the steps.
4. When prompted to clean the scanner click on OK to proceed only if you have already cleaned the scanner
during preparation. Otherwise, follow the instructions on screen and clean the scanner.
