Printing on Both Sides of the Paper
Phaser® 8510/8560MFP Multifunction Product
3-26
Binding Edge Options
When you use the printer driver to select 2-sided printing, also select the binding edge, which
determines how the pages turn. The actual outcome depends on the orientation (portrait or
landscape) of images on the page, as displayed in the following illustrations.
Selecting 2-Sided Printing
To select automatic 2-sided printing:
1. Load paper in the tray.
■ Tray 1: Insert side one faceup with the bottom of the page entering the system first.
■ Tray 2, 3, or 4: Insert side one facedown with the top of the page toward the back of
the tray.
2. Select 2-sided printing in the printer driver.
To select automatic 2-sided printing:
See also:
Loading Paper in Tray 1 on page 3-9
Loading Paper in Tray 2, 3, or 4 on page 3-14
Portrait Landscape
Bind on Side Edge
Flip on Long Edge
Bind on Top Edge
Flip on Short Edge
Bind on Side Edge
Flip on Short Edge
Bind on Top Edge
Flip on Long Edge
Operating System Steps
Windows 98 SE 1. Select the Setup tab.
2. Select Print on 2 Sides.
3. Select or deselect Bind On Top Edge.
Windows 2000,
Windows XP, or
Windows Server 2003
1. Select the Layout tab.
2. Select either Flip On Long Edge or Flip On Short Edge under Print
On Both Sides (Duplex).
Mac OS 9.x 1. In the Print dialog box, select Layout.
2. Select Print on Both Sides.
3. Click the Binding icon that matches the edge to bind.
Mac OS X, version
10.2 and higher
1. In the Print dialog box, select Duplex.
2. Select Print on Both Sides.
3. Click the Binding icon that matches the edge to bind.
