Xerox VersaLink B7035 User Guide

Troubleshooting
Xerox
®
VersaLink
®
B7025/B7030/B7035 Multifunction Printer 201
User Guide
Printer Resets or Powers Off Frequently
Probable Causes Solutions
The power cord is not plugged into the outlet
correctly.
Power off the printer, confirm that the power cord is plugged
in correctly to the printer and the outlet, then power on the
printer.
The power cord is not secured in place
correctly.
Use the bracket provided with the printer to secure the power
cord in place.
A system error occurred.
Power off the printer, then power on again. Print the Error
History Report. For details, refer to Printing the Error History
Report on page
237. If the error persists, contact your Xerox
representative.
The printer is connected to an uninterruptible
power supply.
Power off the printer, then connect the power cord to a
suitable outlet.
The printer is connected to a power strip
shared with other high-power devices.
Plug the printer directly into the outlet or into a power strip
that is not shared with other devices.
Printer Does Not Print
Probable Causes Solutions
The printer is in Power Saver mode.
On the control panel, press the Power/Wake button.
The printer has an error.
If the Status LED is blinking amber, follow the instructions on
the control panel to clear the error. If the error persists,
contact your Xerox representative.
The printer is out of paper. Load paper into the tray.
A toner cartridge is empty. Replace the empty toner cartridge.
The drum cartridge has reached end of life. Replace the drum cartridge.
No control panel indicators are lit.
Power off the printer, confirm that the power cord is plugged
in correctly to the printer and the outlet, then power on the
printer. If the error persists, contact your Xerox representative.
The printer is busy.
• If the Status LED is flashing blue, a previous print job
could be the problem.
a. At your computer, use the printer properties to delet
e
a
ll print jobs in the print queue.
b. At the control panel, touch Jobs, then delete all
pending print jobs.
• Load the paper in the tray.
• If the Status LED does not flash once after you send a
print job, check the connection between the printer and
the computer. Power off the printer, then turn it on again.

Xerox VersaLink B7035 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.4 s
Scan to	E-mail, FTP, SMB, USB
Scanner type	-
Input color depth	24 bit
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Printing colors	Black
Maximum duty cycle	129000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, TIFF, XPS
Internal memory	2048 MB
Processor cores	2
Processor frequency	1050 MHz
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, NFC, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Y
Linux operating systems supported	Fedora 24, openSUSE 13.2
Other operating systems supported	IBM AIX 7.2
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8 x64
Sustainability certificates	ENERGY STAR
Total input capacity	- sheets
Paper tray media types	Bond paper, Card stock, Envelopes, Heavy paper, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	767.9 mm
Weight	- g
