SSL/TLS Settings
IPSec Settings
IEEE 802.1X Settings
Security Settings
FTP Server Login Name
FTP Server Password
Other Settings
Port Settings
Port Settings allow the system administrator to configure the network port services.
All port settings are enabled at install.
Note
While Port 9100, LPD, and SOAP may be displayed on the press screen, they are not
interpreted by the press and not applicable to the press network. Keep these settings at
their default.
Use the default (enable) for the port settings. Manage Print Services and drivers will look
to check that all ports are enabled.
Protocol Settings
Select and configure the Protocol parameters required for communications between the
press and the print server.
There are two modes available: IPv4 and IPv6. If using IPv4 mode, select the DHCP
protocol setting. To use IPv6 mode, keep the IPv4 settings at their default (enabled)
and enable the IPv6 addresses. You can only configure IPv6 through CentreWare Internet
Services.
Select Auto.Ethernet Settings
Never disable IPv4 and select IPv6 only. IPv4
mode is used for print server communication
with the press.
TCP/IP Common Settings
DHCP is the automatic default used to connect
and transfer information between the print
server and the press. When using the DHCP pro-
tocol, the IP Address, Subnet, Gateway, and DNS
Server cannot be changed. These value settings
are automatically retrieved from the print server.
TCP/IP Network Settings
5-3Xerox
®
Versant™ 2100 Press
System Administration Guide
Connectivity & Network Setup
