Hardware User Guide
3-16 Xilinx Development System
J2-5 N.C.
b
J2-6 TRIG XChecker Cable input
that allows an external
event to trigger readback
of the XC4003E or
output a burst of clocks
to the XC4003E.
Connects to tiepoint J10–
1.
J2-7
a
CCLK Provides the clock
during configura-
tion or readback.
Connects to
XC4003E input pin
73.
J2-8 N.C.
b
J2-9
a
DONE Indicates when
configuration is
complete.
Connects to
XC4003E output pin
53.
J2-10 TDI Inputs boundary-scan
data to the XC4003E.
Connects to XC4003E
pin 15.
J2-11
a
DIN Provides configura-
tion data during
configuration.
Connects to
XC4003E DIN input
pin 71.
J2-12 TCK Input boundary scan
clock to the XC4003E.
Connects to pin 16.
J2-13
a
PROG Provides program
pulse causing the
FPGA to configure.
Connects to
XC4003E PROG
input pin 55.
J2-14 TMS Boundary scan mode
input to the XC4003E.
Connects to pin 17.
Table 3-6 XChecker/Parallel Cable III Connector J2
Pin Name Function Pin Name Function
