Xilinx VC709 User Manual

VC709 Evaluation Board www.xilinx.com 21
UG887 (v1.0) February 4, 2013
Feature Descriptions
Additional FPGA bitstreams can be stored and used for configuration by setting the Warm
Boot Start Address (WBSTAR) register contained in 7 series FPGAs. More information is
available in the reconfiguration and multiboot section in 7 Series FPGAs Configuration
User Guide (UG470
).
The configuration section of UG470
provides details on the Master BPI configuration
mode.
Figure 1-4 shows the linear BPI flash memory on the VC709 board. For more details, see the
Numonyx PC28F00AG18FE data sheet (www.micron.com
).
AJ37 FLASH_D3 E4 DQ3
AK37 FLASH_D4 E5 DQ4
AL37 FLASH_D5 G5 DQ5
AN35 FLASH_D6 G6 DQ6
AP35 FLASH_D7 H7 DQ7
AM37 FLASH_D8 E1 DQ8
AG33 FLASH_D9 E3 DQ9
AH33 FLASH_D10 F3 DQ10
AK35 FLASH_D11 F4 DQ11
AL35 FLASH_D12 F5 DQ12
AJ31 FLASH_D13 H5 DQ13
AH34 FLASH_D14 G7 DQ14
AJ35 FLASH_D15 E7 DQ15
AM34 FLASH_WAIT F7 WAIT
BB41 FPGA_FWE_B G8 WE_B
BA41 FLASH_OE_B F8 OE_B
N10 FPGA_CCLK E6 CLK
AL36 FLASH_CE_B B4 CE_B
AY37 FLASH_ADV_B F6 ADV_B
AG11 FPGA_INIT_B D4 RST_B
Table 1-6: BPI Flash Memory Connections to the FPGA (Cont’d)
FPGA (U1) Pin Net Name
BPI Flash Memory (U3)
Pin Number Pin Name
