Xilinx VC709 User Manual

32 www.xilinx.com VC709 Evaluation Board
UG887 (v1.0) February 4, 2013
Chapter 1: VC709 Evaluation Board Features
For more information on the GTH transceivers see 7 Series FPGAs GTX/GTH Transceivers
User Guide (UG476
).
MGTREFCLK1 PCIe_CLK
MGT_BANK_117 GTHE2_CHANNEL_X1Y31 NC
GTHE2_CHANNEL_X1Y30 NC
GTHE2_CHANNEL_X1Y29 FMC2 HPC DP8
GTHE2_CHANNEL_X1Y28 FMC2 HPC DP9
MGTREFCLK0 NC
MGTREFCLK1 NC
MGT_BANK_118 GTHE2_CHANNEL_X1Y35 FMC1 HPC DP7
GTHE2_CHANNEL_X1Y34 FMC1 HPC DP6
GTHE2_CHANNEL_X1Y33 FMC1 HPC DP5
GTHE2_CHANNEL_X1Y32 FMC1 HPC DP4
MGTREFCLK0 FMC1 HPC GBT_CLK1
MGTREFCLK1 FMC2 HPC GBT_CLK0
MGT_BANK_119 GTHE2_CHANNEL_X1Y39 FMC1 HPC DP3
GTHE2_CHANNEL_X1Y38 FMC1 HPC DP2
GTHE2_CHANNEL_X1Y37 FMC1 HPC DP1
GTHE2_CHANNEL_X1Y36 FMC1 HPC DP0
MGTREFCLK0 NC
MGTREFCLK1 NC
Table 1-9: GTH Interface Connections to the FPGA (U1) (Cont’d)
Transceiver Bank Net Name Connections
