ZC702 Board User Guide www.xilinx.com 37
UG850 (v1.7) March 27, 2019
Feature Descriptions
Table 1-17 lists the connections between the codec and the XC7Z020 SoC.
Table 1-18 lists the connections between the codec and the HDMI receptacle P1.
Table 1-17: XC7Z020 SoC to HDMI Codec Connections (ADV7511)
XC7Z020 (U1) Pin Net Name I/O Standard
ADV7511 (U40)
Pin Name
AB21 HDMI_D0 LVCMOS25 88 D8
AA21 HDMI_D1 LVCMOS25 87 D9
AB22 HDMI_D2 LVCMOS25 86 D10
AA22 HDMI_D3 LVCMOS25 85 D11
V19 HDMI_D4 LVCMOS25 84 D12
V18 HDMI_D5 LVCMOS25 83 D13
V20 HDMI_D6 LVCMOS25 82 D14
U20 HDMI_D7 LVCMOS25 81 D15
W21 HDMI_D8 LVCMOS25 80 D16
W20 HDMI_D9 LVCMOS25 78 D17
W18 HDMI_D10 LVCMOS25 74 D18
T19 HDMI_D11 LVCMOS25 73 D19
U19 HDMI_D12 LVCMOS25 72 D20
R19 HDMI_D13 LVCMOS25 71 D21
T17 HDMI_D14 LVCMOS25 70 D22
T16 HDMI_D15 LVCMOS25 69 D23
T18 HDMI_DE LVCMOS25 97 DE
R15 HDMI_SPDIF LVCMOS25 10 SPDIF
L16 HDMI_CLK LVCMOS25 79 CLK
H15 HDMI_VSYNC LVCMOS25 2 VSYNC
R18 HDMI_HSYNC LVCMOS25 98 HSYNC
U14 HDMI_INT LVCMOS25 45 INT
H20 HDMI_SPDIF_OUT LVCMOS25 46 SPDIF_OUT
Table 1-18: ADV7511 to HDMI Receptacle Connections
ADV7511 (U40) Net Name HDMI Receptacle P1 Pin
36 HDMI_D0_P 7
35 HDMI_D0_N 9
40 HDMI_D1_P 4
39 HDMI_D1_N 6
43 HDMI_D2_P 1
