Xilinx ZC702 User Manual

ZC702 Board User Guide www.xilinx.com 58
UG850 (v1.7) March 27, 2019
Feature Descriptions
G3 FMC2_LPC_CLK1_M2C_N LVCMOS25 Y5 H2 FMC2_LPC_PRSNT_M
2C_B
G6 FMC2_LPC_LA00_CC_P LVCMOS25 Y19 H4 FMC2_LPC_CLK0_M2
C_P
LVCMOS25 Y18
G7 FMC2_LPC_LA00_CC_N LVCMOS25 AA19 H5 FMC2_LPC_CLK0_M2
C_N
LVCMOS25 AA18
G9 FMC2_LPC_LA03_P LVCMOS25 AA16 H7 FMC2_LPC_LA02_P LVCMOS25 V14
G10 FMC2_LPC_LA03_N LVCMOS25 AB16 H8 FMC2_LPC_LA02_N LVCMOS25 V15
G12 FMC2_LPC_LA08_P LVCMOS25 AA17 H10 FMC2_LPC_LA04_P LVCMOS25 V13
G13 FMC2_LPC_LA08_N LVCMOS25 AB17 H11 FMC2_LPC_LA04_N LVCMOS25 W13
G15 FMC2_LPC_LA12_P LVCMOS25 W15 H13 FMC2_LPC_LA07_P LVCMOS25 T21
G16 FMC2_LPC_LA12_N LVCMOS25 Y15 H14 FMC2_LPC_LA07_N LVCMOS25 U21
G18 FMC2_LPC_LA16_P LVCMOS25 AB14 H16 FMC2_LPC_LA11_P LVCMOS25 Y14
G19 FMC2_LPC_LA16_N LVCMOS25 AB15 H17 FMC2_LPC_LA11_N LVCMOS25 AA14
G21 FMC2_LPC_LA20_P LVCMOS25 T4 H19 FMC2_LPC_LA15_P LVCMOS25 Y13
G22 FMC2_LPC_LA20_N LVCMOS25 U4 H20 FMC2_LPC_LA15_N LVCMOS25 AA13
G24 FMC2_LPC_LA22_P LVCMOS25 U10 H22 FMC2_LPC_LA19_P LVCMOS25 R6
G25 FMC2_LPC_LA22_N LVCMOS25 U9 H23 FMC2_LPC_LA19_N LVCMOS25 T6
G27 FMC2_LPC_LA25_P LVCMOS25 AA12 H25 FMC2_LPC_LA21_P LVCMOS25 V5
G28 FMC2_LPC_LA25_N LVCMOS25 AB12 H26 FMC2_LPC_LA21_N LVCMOS25 V4
G30 FMC2_LPC_LA29_P LVCMOS25 AA11 H28 FMC2_LPC_LA24_P LVCMOS25 U6
G31 FMC2_LPC_LA29_N LVCMOS25 AB11 H29 FMC2_LPC_LA24_N LVCMOS25 U5
G33 FMC2_LPC_LA31_P LVCMOS25 AB10 H31 FMC2_LPC_LA28_P LVCMOS25 AB5
G34 FMC2_LPC_LA31_N LVCMOS25 AB9 H32 FMC2_LPC_LA28_N LVCMOS25 AB4
G36 FMC2_LPC_LA33_P LVCMOS25 Y11 H34 FMC2_LPC_LA30_P LVCMOS25 AB7
G37 FMC2_LPC_LA33_N LVCMOS25 Y10 H35 FMC2_LPC_LA30_N LVCMOS25 AB6
G39 VADJ H37 FMC2_LPC_LA32_P LVCMOS25 Y4
H38 FMC2_LPC_LA32_N LVCMOS25 AA4
H40 VADJ
Table 1-29: LPC Connections, FMC2 (J4) to SoC U1 (Cont ’d)
FMC2
J4 Pin
Net Name
I/O
Standard
XC7Z020
(U1) Pin
FMC2
J4 Pin
Net Name
I/O
Standard
XC7Z020
(U1) Pin
