Xilinx ZC702 User Manual

ZC702 Board User Guide www.xilinx.com 57
UG850 (v1.7) March 27, 2019
Feature Descriptions
Table 1-29 shows the LPC connections between FMC2 (J4) and SoC U1.
Table 1-29: LPC Connections, FMC2 (J4) to SoC U1
FMC2
J4 Pin
Net Name
I/O
Standard
XC7Z020
(U1) Pin
FMC2
J4 Pin
Net Name
I/O
Standard
XC7Z020
(U1) Pin
C2 NC D1 PWRCTL2_VCC4A_PG
C3 NC D4 NC
C6 NC D5 NC
C7 NC D8 FMC2_LPC_LA01_CC_
P
LVCMOS25 W16
C10 FMC2_LPC_LA06_P LVCMOS25 U17 D9 FMC2_LPC_LA01_CC_
N
LVCMOS25 Y16
C11 FMC2_LPC_LA06_N LVCMOS25 V17 D11 FMC2_LPC_LA05_P LVCMOS25 AB19
C14 FMC2_LPC_LA10_P LVCMOS25 Y20 D12 FMC2_LPC_LA05_N LVCMOS25 AB20
C15 FMC2_LPC_LA10_N LVCMOS25 Y21 D14 FMC2_LPC_LA09_P LVCMOS25 U15
C18 FMC2_LPC_LA14_P LVCMOS25 T22 D15 FMC2_LPC_LA09_N LVCMOS25 U16
C19 FMC2_LPC_LA14_N LVCMOS25 U22 D17 FMC2_LPC_LA13_P LVCMOS25 V22
C22 FMC2_LPC_LA18_CC_P LVCMOS25 AA9 D18 FMC2_LPC_LA13_N LVCMOS25 W22
C23 FMC2_LPC_LA18_CC_N LVCMOS25 AA8 D20 FMC2_LPC_LA17_CC_
P
LVCMOS25 AA7
C26 FMC2_LPC_LA27_P LVCMOS25 AB2 D21 FMC2_LPC_LA17_CC_
N
LVCMOS25 AA6
C27 FMC2_LPC_LA27_N LVCMOS25 AB1 D23 FMC2_LPC_LA23_P LVCMOS25 V12
C30 FMC2_LPC_IIC_SCL D24 FMC2_LPC_LA23_N LVCMOS25 W12
C31 FMC2_LPC_IIC_SDA D26 FMC2_LPC_LA26_P LVCMOS25 U12
C34 GA0 = 0 = GND D27 FMC2_LPC_LA26_N LVCMOS25 U11
C35 VCC12_P D29 FMC2_LPC_TCK_BUF
C37 VCC12_P D30 FMC1_LPC_TDO_FMC
2_LPC_TDI
C39 VCC3V3 D31 FMC2_LPC_TDO_FPG
A_TDI
D32 VCC3V3
D33 FMC2_LPC_TMS_BUF
D34 NC
D35 GA0 = 0 = GND
D36 VCC3V3
D38 VCC3V3
D40 VCC3V3
G2 FMC2_LPC_CLK1_M2C_P LVCMOS25 Y6 H1 NC
