12V output. Connecting this output to any
input enables that input.
The first terminal (from the right side) is 12 V. it is the supply
for signals, and its ground is the COM terminal.
Rescue Speed
The rescue speed input is enabled by the UPS
in emergency situations and the inverter will
control the motor. It is also possible to set
this input for other speeds or the Enable
input if necessary.
The setting of this parameter is in the
parameter.
In the rescue mode, in addition to the I7
input, one of the I1 or I2 inputs which
determine the direction, must be enabled to
direct the motor to the nearest floor.
Input Enable
This input must be connected in series with
the safety circuit of the control panel and the
first contactor before the motor (using the
auxiliary contact of the first contactor).
In this case, as long as the safety circuit and
contactor No. 1 are not closed, the Enable
input will not be activated.
These inputs are enabled by connecting to the 12 V terminal
of the device. (Note that if an external voltage is being used, it
should not be less than 9 V and more than 30 V, and also the
common (COM) PLC (Programmable Logic Controller) must be
connected to the COM terminal of the inverter.)
12V output ground to feed the sensor or
other similar components.
Special relay for connection to the contactor
According to the standard, this unique feature of the Xima
inverter, converts two electromechanical elements required
