before the motor to one mechanical element (contactor 1) and
one inverter output relay.
In fact, the Xima inverter becomes Contactor Less, and
according to the EN81 standard, it places two
electromechanical elements before the motor for more safety .
Digital relay No. 1 of the inverter. Refer to parameter 
for information about other settings.
250V/1A
Brake relay
RELAY-2
13
Special relay for connection to the brake
Digital relay No. 2 of the inverter. Refer to parameter 
for information about other settings.
250/1A
Fault Relay
RELAY-3
14
Special relay for fault
Digital relay No. 3 of the inverter. Refer to parameter 
for information about other settings.
50mA
Open collector digital output of the device.
Refer to parameter 5
OP 2
15
It is the digital output of the device and the ground of this
output is the COM terminal.
Note that, this collector output is open and in some cases it
must be connected to a 12V terminal with a maximum
resistance of 1 kΩ so that the desired pulse would be created.
-
Programing
RJ45
16
This terminal is used to program and to update the
Table 7: Inputs/Outputs of the control circuit
