35
Parameter
Name
Setting range
Default value
Type
Multi speed 4
1
0
0

Multi speed 5
1
0
1

Multi speed 6
1
1
0

Multi speed 7
1
1
1

2 & 3 - Serial communication method
In this method, different speeds are selected by the control panel using
the serial communication between the control panel and the inverter.
4 – Serial communication in Modbus RTU
In this mode different commands and speeds can be set via a standard
Modbus RTU communication by a computer or a PLC.
5- lifting mode
in this mode, I1 terminal will be the “up”, I2 “down” and I3 “fast stop”
command. The output frequency (speed), will be set by “PA4”
parameter. You can exchange the I1 and I2 terminals with I7, by the
“Pc07” parameter, but I3 terminal cannot be changed with I7.

Relay 1 Setting
0-8
0
R/W
Relay 1 Setting which is defined for the contactor command by default.
❖ Refer to relay and digital outputs settings.

Relay 2 Setting
0-8
1
R/W
Relay 2 Setting which is defined for the brake command by default.
❖ Refer to relay and digital outputs settings.

Relay 3 Setting
0-8
2
R/W
Relay 3 Setting which is defined for inverter faults by default .
❖ Refer to relay and digital outputs settings.

OP 2 Setting
0-8
3
R/W
Settings of the output digital (open collector) number 1, which is set for
Enable feedback by default.
❖ Refer to relay and digital outputs settings.
