Xinje DS2 series Manual

54
06
Command pulse frequency at
rated speed
100
Hz
5000
1～
10000
○
7
07
Speed command pulse filter
time
0.1
ms
20
0～1000
√
7
08
Reserved
09
Reserved
10
Internal position mode
-
n.0000
○
5
11
First segment of pulse (low
bit)
1
0
-9999～
+9999
√
5
12
First segment of pulse (high
bit)
1
0
-9999～
+9999
√
5
13
First segment speed
0.1
rpm
0
0～
50000
√
5
14
First segment adjusting time
1ms
0
0～
65535
√
5
15
First segment command filter
time
0.1
ms
0
0～
65535
√
P2-16~P2-90 are 2~16 segment parameters, P2-91~P2-93 are reserved.
94.
xx□x
Search 0 point function on or
off
0:search 0 point function is
off
1:search 0 point function is
on
-
0
0~1
○
5, 6
94.
xxx□
The times pass Z phase
signal after leaving the limit
switch
time
s
2
1~65535
○
5, 6
