XO FLEX
–
Instructions for use
Configuration
52
Parameter
Display text
Factory default
configuration
Possible settings
Amount of irrigati
on
water
–
Level 1
W LEVEL 1
20 ml/min
10
–
90
+
10% ml/min
XO ODONTOCURE
curi
ng
light
Curing time 3
TIME 3
20 s
1
–
300 s
Curing time 2
TIME 2
10 s
1
–
300 s
Curing time 1
TIME 1
5 s
1
–
300 s
Soft
-
start
SOFT T.
Disabled
Enabled/disabled
Soft
-
start
SOFT T.
5 s
1
–
300 s 20% power
If the unit is fitted with two or more identical unit instrumen
ts (e.g. two micro
motors),
the configured data (e.g. amount of spray water)
will apply to
all identical unit
instruments.
51
53
Table of Contents
Default Chapter
3
Table of Contents
3
1 Extraordinary Dentistry
7
2 Installation
8
3 Operation
11
General
11
Switch the Unit on
12
Instrument Bridge in Parking Position
13
Foot Control
13
Function
13
Position the Foot Control
14
Xo Smart Link
15
Patient Chair
15
Foot Control of Patient Chair
15
Smaller Adjustments of Patient Chair
15
Safety
16
Supine Patient Position
16
Neck Rest
16
Child Cushion
17
Instrument Bridge in Working Position
17
Balanced Instruments
17
Four-Handed or solo Work
18
Working Positions
18
Instrument Control
21
Foot Control of Instruments
21
Instruments on the Instrument Bridge
21
Instrument Bridge Display
21
Syringe - Luzzani
22
Micromotor - Bien-Air MC3 / Bien-Air MX2
22
XO OSSEO Motor
23
Set-Up
23
Operation
24
Implant Surgery - Operation with XO Smart Link
25
Air Instrument
25
Ultrasonic Scalers
26
XO ODONTOSON 360 Ultrasonic Scaler
27
How to Use XO ODONTOSON 360
28
Changing the Instrument
29
XO ODONTOSON 360 with Antimicrobials and Sterile Saline
30
XO ODONTOCURE Curing Light
30
XO Peristaltic Pump
32
Disposable Irrigation Kit
32
Attaching the Pump Module
33
Attaching the Irrigation Tube
33
Irrigation Bag
35
Irrigation Reservoir
35
Designation of Instrument
36
Adjusting the Flow Level
37
Intraoral HD Video Camera
37
Operating Light
38
Position the Light
38
Switch the Light on and Adjust the Light Intensity
39
Automatic Functions
40
XO HD Display
40
Hand Instruments
41
Suction
42
Cuspidor and Cup Filler
42
Automatic Function
43
Assistant Call
43
Sound Generator and Sounds
44
System Messages
44
XO SEAT and XO STOOL
44
Xo Seat
45
Xo Stool
46
4 Configuration
48
Configuration of Patient Chair Positions
48
Configuration of General Unit and Patient Chair Functions
48
Configuration of Unit Instruments
49
5 Cleaning and Infection Control
53
Cleaning, Disinfection and Sterilization Procedures
53
Detergents and Disinfectants for Cleaning And/Or Disinfection of the Unit
53
General Cleaning of Unit and Patient Chair Surfaces
53
Cleaning of Comfort and Skai Fabric
54
General Disinfection of Unit Surfaces
54
Infection Control Instrument and Bridge Protection Pad
54
Autoclaving Handles
54
Disinfection of Instrument Hoses and Suspensions
55
Infection Control Luzzani Syringe
56
Infection Control Bien-Air Micromotors
56
Autoclaving of XO OSSEO Motor
56
Infection Control XO ODONTOSON 360
57
Infection Control XO ODONTOCURE Curing Light
57
Infection Control Other Instruments
58
Infection Control XO Peristaltic Pump
58
Disinfection of Light
58
Infection Control XO HD Display
59
Front Panel
59
Disinfection of Cuspidor Bowl and Cup Holder
59
Disinfection of Suction Lines
60
General
60
Suction Filters
61
Replacement of XO Suction Disinfection Cartridge
62
Disinfection of Unit Water Lines
63
Overnight Water Treatment
63
Intensive Water Treatment
64
Replacement of XO Water Clean Cartridge
64
6 Maintenance and Repairs
66
Foot Control
66
XO OSSEO Motor
66
Motor Repair
66
Xo Odontoson
66
Handpiece Repair
66
Tightening / Exchanging the Ferrite Rod
66
Xo Odontocure
67
Handpiece Repair
67
Manual Measurement of Curing Effectiveness
67
XO Peristaltic Pump
69
Adjustment of the Hand Instrument Table
69
Control of the Water Disinfection System
69
Maintenance and Replacement of Main Filter for Water Supply
70
Cuspidor Valve - Cleaning the Course Filter
70
Flushing of Cuspidor Drain
70
Suction Hoses
70
Air and Amalgam Separator
71
Dürr CS1 Combi-Sepamatic - Air Separator
71
Dürr CAS 1 Combi-Separator - Air and Amalgam Separator
71
7 Unit Messages and Remedial Actions
72
Error Messages
72
Service Messages and Remedial Actions
73
8 Preventive Service, Safety Inspections and Repairs
74
General
74
Preventive Service and Safety Inspection
74
Preventive Service and Safety Inspection a - 12, 36 Etc. Months after Installation
74
Preventive Service and Safety Inspection B - 24, 48 Etc. Months after Installation
74
Service Notification
74
Adjustment of the Arm Systems
75
Adjustment of Balanced Instrument Suspension Arms
75
Replacement of Operating Light Source
75
XO HD Display
75
9 Infection Control and Maintenance Checklist
76
10 Accessories, Detachable Parts and Consumables
78
Accessories
78
Detachable Parts
78
Consumables
79
Suggested Retail Prices
80
11 Legal
81
Modification of the Equipment
81
Warrantee
81
Expected Service Life
81
Rd Party Instruments and Accessories
82
Product Updates
82
Firmware Version
82
Applicable Standards
82
Electromagnetic Emission
82
Interference Immunity
83
Classification
84
Applied Parts
84
Marking Plate
84
Other Labels
85
Product Disposal Information
85
12 Symbols
86
13 Dimensions and Technical Data
89
Dimensions and Range of Movement
89
Technical Specifications
90
14 XO FLEX Quick Guide
93
