XO FLEX – Instructions for use Dimensions and technical data
91
Part
Specification
Irrigation
10 – 90 ml/min + 20%
XO ODONTOCURE
Light source
LED
Wave lengths
385 – 515 nm (peaks at 400 nm ±10 nm and at 460 ± 3
nm)
Power output – Normal mode
1650 mW/cm
2
Power output – Soft Start
375 mW/cm
2
Fiber glass rod outer diameter
8 mm
Cross-sectional area of optics (effective)
0,44 cm
2
(44,2 mm
2
)
Hand piece temperature during use
46°C
Curing activator classification
Class 2, Type 1
Patient chair
Maximum load
150 kg
Drive motors for chair and backrest
25 seconds ON – 400 seconds OFF
Operating light
Light intensity
3,000 – 30,000 lux
Color rendering index (CRI)
> 95
Color temperature
5,500 K
Illuminance pattern
In accordance with
ISO 9680 - see Figure 92 below
Suction
The unit shall be connected to a suction machine
with
High flow rate
Type of suction
Wet or dry
Inner diameter of high volume suction nozzle
16 mm
Inner diameter of saliva suction nozzle
7 mm
Head loss between the suction installation and
the atmospheric end of the high-volume suction
cannula
Flow [l/min]
Head loss [mbar]
250
33,9
300
59,3
350
84,7
450
110,1
Head loss between the suction installation and
the atmospheric end of the saliva suction cannula
Flow [l/min]
Head Loss [mbar]
250
33,9
300
42,3
350
67,7
450
84,7
Mesh size suction filters
< 1 mm
Weighted noise level from the suction system
through the connected cannulas at a distance of
0.5 m from the cannula connect
<65 dB (A)
Water and air supply
Mesh size air filter
5
µ
m
Mesh size water filter
50 µm
Maximum inlet water conductivity
850 µS/m
Water disinfection (XO Water Clean)
Continuously dispersion of a solution of non-
toxic disinfectant to the procedural water.
0.0235% hydrogen peroxide
Water heater
Maximum power loading
55 W
