Xycom 3510T - I;O Panel 3510;1512; I;O Panel 3535

Chapter Three - Installation
23
I/O Panel 3510/1512
COM 2
RS-232
PARALLEL RS-232
COM 1
RS-485
MOUSE
KEYBD
VIDEO
LID
LID
REMOVAL
SCREW (2)
ETHERNET
PORT
MOUNTING
STUD (12)
FRONT PANEL
EXPANSION SLOTS (3)
USB PORT (2)
Figure 3-3. System I/O 3510/1512Panel
I/O Panel 3535
COM 2
RS-232
PARALLEL
RS-232
COM 1
RS-485
MOUSE
KEYBD
VIDEO
LID
LID
REMOVAL
SCREW (2)
ETHERNET
PORT
MOUNTING
STUD (12)
FRONT PANEL
EXPANSION SLOTS
(
3
)
USB PORT
(
2
)
Figure 3-4 System 3535 I/O Panel
