Power Supply
The power supply provides 80 watts of output throughout the system’s temperature
range. The expansion power is limited as shown in the following table.
Available Expansion Current
Voltage Available Current
AHIP4+ (5x86 processors)
a
AHIP-370
(Celeron and Pentium II/III processors)
b
+5 VDC 6.17A +3.3 9A
+12 VDC 1.88A +5 6A
-12 VDC 0.71A +12 1.5A
-12 .45A
a
Total expansion power not to exceed 46 watts
b
Total expansion power not to exceed 48 watts
