Appendix A – Technical Specifications
89
Appendix A – Technical Specifications
Hardware Specifications
Characteristic 3510/3512KP 3535KPM
Mechanical
Height
Width
Depth
Weight
11.0” Front Panel, 12.25” (KP units)
13.0” Front Panel, 16.50” (KP units)
6.5” overall
5.65” behind front panel
1.00” front panel protrusion
7.4” overall with back-mounted external
floppy
16 lbs, 18 lbs with external floppy
14.2”
19”
9.75” (9.00”)
42 lbs
Electrical
AC
DC
115/230 VAC - 50-60 Hz - 3.0/1.5 A
20-36 VDC - 24 V nominal - 10 A max
115/230 VAC - 50-60 Hz - 3.0/1.5 A
autosensing
Power Supply 80 Watts 80 Watts
Passive Backplane One ISA slot
One PCI slot
One PCI or PCI bus ¾ length expansion
slot
One ISA slot
One PCI slot
One PCI or PCI bus ¾ length expansion
slot
Available Power
ab
With AHIP-370 CPU board
+3.3 V, 9 A
+5 V, 6A
+12 V, 1.5A
-12 V, 0.71A
CAUTION: Total expansion power not to
exceed 48 watts.
With AHIP-370 CPU board
+3.3 V, 9 A
+5 V, 6A
+12 V, 1.5A
-12 V, 0.71A
CAUTION: Total expansion power not to
exceed 48 watts.
Mounting Panel mount or 19” rack with optional filler
plate
Panel mount or 19” rack mount
Flat Panel 10.4” TFT active color display
12.1” TFT active color display
15” TFT XGA color display (1024 x768)
Agency Approvals UL 1950
UL 1604
CUL C22.2, No. 950
CUL C22.2, No. 213
UL 1950
UL 1604
CUL C22.2, No. 950
CUL C22.2, No. 213
Regulatory
Compliance
FCC: 47 CFR. Part 15, Class A
CE:
FCC 47 CFR. Part 15, Class A
CE:
