3500 Series Flat Panel Industrial PC
94
Dual USB Connector (USB1)
This connector is only available on units with AHIP6+ boards.
Pin Number Description Pin Number Description
1A 5VFUSE 1B 5VFUSE
2A USBP0- 2B USBP1-
3A USBP0+ 3B USBP1+
4A GND 4B GND
Parallel Port Connector (LPT1)
This is a 25-pin DB connector.
Pin Signal Pin Signal
1A STROBE 14A AUTOFEED
2A PD(0) 15A PERROR
3A PD(1) 16A INIT
4A PD(2) 17A SELIN
5A PD(3) 18A GND
6A PD(4) 19A GND
7A PD(5) 20A GND
8A PD(6) 21A GND
9A PD(7) 22A GND
10A PACK 23A GND
11A PBUSY 24A GND
12A PE 25A GND
13A SELECT
Serial Port Connectors
Serial ports RS-232 and RS-485 are supported on the AHIP4+ and the AHIP6+ boards.
Only one connector can be used at a time. All termination is done outside the unit.
