Chapter Three - Installation
29
Installing External Hardware Options
This section explains how to install the external hardware options available with the
system.
Note
When using the external floppy drive, do NOT attach the drive with a diskette installed.
You may corrupt the disk.
9000-EXF External Floppy Drive
The external floppy (9000-EXF) can be mounted on the back of the unit. There are
four screw holes on the back of the unit for the floppy mounting. A fifth screw hole
is on the back for the cable clamp screw. See the Figures 3.4 and 3.7 of the back
panel and the bottom panel.
Front mounting options are also available.
Note
Make sure the floppy drive cable will reach the external floppy connector on the system
before making the cutout.
9000-FFK External Front Floppy and Keyboard Access Kit
If you want to relocate the floppy drive to the front of the computer module, you
must install the 9000-FFK (Front Floppy Keyboard Access Kit), which includes a
front access keyboard port. The floppy drive access door is provided for installations
using the 9000-RFC Rack Filler Plate with Cutout, or panel mount installations that
provide a cutout for the front mounted floppy drive.
