Xycom 3510T - Page 55

Chapter Three - Installation
55
3510KP/3512KP, 3510KPT/3512KPT
.800 [20.32] 1.150 [29.21]
5.775 [146.69]
10.400 [264.16]
11.55
0
[293.37]
ø.250 [ø6.35]
.350 [8.89]
1.650 [41.91]
7.900 [200.66]
14.150 [359.41]
15.800 [401.32]
15.100 [383.54]
10.850 [275.59]
Figure 3-24. 3510KP/3512KP System Cutout Dimensions (inches [mm])
3535KPM and 3535T
3.857 [97.97]
.457 [11.61]
9.157 [232.59]
14.457 [367.21]
18.312 [465.12]
.685 [17.40]
1.085 [27.56]
5.085 [129.16]
8.085 [205.36]
12.085 [306.96]
13.170 [334.52]
17.400 [441.96]
12.370 [314.20]
ø.250 [ø6.35]
Figure 3-25. 3535KP System Cutout Dimensions (inches [mm])
