Xylem hydrovar User Manual

P262 SKIP FRQ.RNG.
0.0 Hz
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
P265 MOTOR NOM.POWER
Sets the nominal power of the motor coupled with HYDROVAR, as reported in the motor
nameplate.
P265 MOTOR NOM.POWER
1.5 kW
Actual Value Output Freq.
Left fct. Up fct. Down fct. Right fct.
Possible settings are:
HVL Undersized motor 2 Undersized motor 1 Default Oversized motor
2,015 0.75 kW - 1.0 hp 1.1 kW - 1.5 hp 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp
2,022 1.1 kW - 1.5 hp 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp
2,030 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp
2,040 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp
3,015 0.75 kW - 1.0 hp 1.1 kW - 1.5 hp 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp
3,022 1.1 kW - 1.5 hp 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp
3,030 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp
3,040 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp
3,055 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp 7.5 kW - 10.0 hp
3,075 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp 7.5 kW - 10.0 hp 11.0 kW - 15.0 hp
3,110 5.5 kW - 7.5 hp 7.5 kW - 10.0 hp 11.0 kW - 15.0 hp 15.0 kW - 20.0 hp
4,015 0.75 kW - 1.0 hp 1.1 kW - 1.5 hp 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp
4,022 1.1 kW - 1.5 hp 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp
4,030 1.5 kW - 2.0 hp 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp
4,040 2.2 kW - 3.0 hp 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp
4,055 3.0 kW - 4.0 hp 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp 7.5 kW - 10.0 hp
4,075 4.0 kW - 5.0 hp 5.5 kW - 7.5 hp 7.5 kW - 10.0 hp 11.0 kW - 15.0 hp
4,110 5.5 kW - 7.5 hp 7.5 kW - 10.0 hp 11.0 kW - 15.0 hp 15.0 kW - 20.0 hp
4,150 7.5 kW - 10.0 hp 11.0 kW - 15.0 hp 15.0 kW - 20.0 hp 18.5 kW - 25.0 hp
4,185 11.0 kW - 15.0 hp 15.0 kW - 20.0 hp 18.5 kW - 25.0 hp 22.0 kW - 30.0 hp
4,220 15.0 kW - 20.0 hp 18.5 kW - 25.0 hp 22.0 kW - 30.0 hp 30.0 kW - 40.0 hp
P266 MOTOR NOM.VOLT.
Sets the motor nominal voltage, as reported in the motor nameplate, according to
• the chosen motor connection
• the output voltage of the HYDROVAR
8 Programming
HVL 2.015-4.220 Installation, Operation, and Maintenance Manual 63
