Parts List – SMX 2500 - High-Low Shift Clutch (Figure 47)
ITEM
P/N
DESCRIPTION
QTY
1
VS75
FRU-K3-BEARING SLIDING HOUSING
1
2
23970
FRU-K3-BALL BEARING 6908ZZ
1 SET
3
VS78
FRU-K3-BEARING SPACER
1
4
VS79
FRU-K3-BEARING SPACER
1
5
VS80
FRU-K3-SNAP RING R-65
1
6
VS73
FRU-K3-SPLINED GEAR HUB
1
7
VS72
FRU-K3-KEY 8x7x10L
1
8
VS74
FRU-K3-SPINDLE BULL GEAR
1
9
VS114
FRU-K3-WASHER
1
10
VS115
FRU-K3-EXTERNAL TOOTH WASHER Ø 40
1
11
VS81
FRU-K3-LOCK WASHER Ø 9/16-18NC
1
12
VS76
FRU-K3-RING
1
13
20817
SPACER-BEARING
1
i00692-K2-K3
