XYZ Machine Tools SMX 5000 User Manual

136
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 2500 - Lower Head Assembly (Figure 54)
ITEM
P/N
DESCRIPTION
QTY
1
K-B125-2
FRU-K3-HANDWHEEL HANDLE (AVAILABLE ONLY IN ASSY. 20835)
1
2
K-B113
FRU-K3-HAND WHEEL CLUTCH
1
3
K-B117
FRU-K3-ROLL PIN Ø3x15L
1
4
K-B103
FRU-K3-CAM ROD
1
5
K-B108
FRU-K3-SOCKET SET SCREW M6-P1.0x8L
1
6
K-B119-1
FRU-K3-ROLL PIN Ø3x20L
1
7
K-B103-1
FRU-K3-CAM ROD PIN Ø6x15L
1
8
K-B107
FRU-K3-CAP SCREW M6-P1.0x25L
2
9
K-B106
FRU-K3-FEED TRIP BRACKET
1
10
20779-4
FRU-SK2/SK3-OVERLOAD CLUTCH TRIP SUB-ASSY (3VK-B4)
1
11
K-B73
FRU-K3-SOCKET SET SCREW M6-P1.0x20L
1
12
K-B101
FRU-K3-CHEM BLACKED LOCKNUT M6-P1.0
1
13
K-B99
FRU-K3-CLUTCH ARM COVER
1
15
20779-2
FRU-SK2/SK3-QUILL FEED SELECTOR SUB-ASSY (3VK-B2)
1
16
K-B67
FRU-K3-CAP SCREW M6-P1.0x18L
4
17
K-B29
FRU-K3-CLUSTER GEAR KEY 3x3x45L
1
18
K-B27
FRU-K3-CLUSTER GEAR SHAFT UPPER BEARING
1
19
K-B28
FRU-K3-CLUSTER GEARS ASSEMBLY
1
20
K-B94
FRU-K3-SNAP RING 95 DOWEL PIN Ø 14
1
21
K-B32
FRU-K3-BEVEL GEAR THRUST SPACER
1
22
K-B33
FRU-K3-BEVEL GEAR BEARING
1
23
K-B31
FRU-K3-CLUSTER GEAR SHAFT 6602BB
1
24
20779-1
FRU-SK2/SK3-WORM GEAR CRADLE SUB-ASSY (3VK-B1)
1
25
K-B18
FRU-K3-WORM GEAR CRADLE THROW-OUT
1
26
K-B19
FRU-K3-SHIFT SLEEVE
1
27
K-B25
FRU-K3-CAP SCREW (3REQ.) M5-P0.8x12L
3
28
K-B20
FRU-K3-GEAR SHIFT PLUNGER
1
29
K-B21
FRU-K3-COMPRESSION SPRING
1
30
K-B22
FRU-K3-ROLL PIN Ø3x20L
1
31
K-B23
FRU-K3-SHIFT CRANK
1
33
K-B186
FRU-K3-WORM GEAR
1
34
K-B128
FRU-K3-QUILL SKIRT
1
35
K-B189-1
FRU-K3-ADJ WORM SHAFT SET SCREW M6-P1.0x6L
1
36
K-B42
FRU-K3-BUSHING
2
37
K-B187
FRU-K3-KEY 4x4x18L
1
38
K-B189
FRU-K3-ADJ WORM SHAFT
1
39
K-B171
FRU-K3-KEY 3x3x20L
1
40
K-B178
FRU-K3-CLOCK SPRING
1
41
K-B177
FRU-K3-SPRING COVER
1
42
K-B169
FRU-K3-RD.HEAD SCREW (2REQ.) M5-P0.8x15L
2
43
K-B170
FRU-K3-ROLL PIN
1
44
K-B175-3
FRU-K3-SET SCREW M8-P1.25x6L
2
45
K-B175-2
FRU-K3-COMPRESSION SPRING
2
46
K-B175-1
FRU-K3-STEEL BALL
2
47
K-B176
FRU-K3-PINION SHAFT HUB SLEEVE
1
48
K-B175
FRU-K3-RACK FEED HANDLE HUB
1
49
K-B172
FRU-K3-PINION SHAFT HUB SCREW
1
50
K-B142
QUILL
0
51
VS109
FRU-K3-DRAWBAR 7/16-20UNF
1
52
VS109-1
FRU-K3-SPACER
1
