XYZ Machine Tools SMX 5000 User Manual

137
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
53
K-B191
FRU-K3-BLACK PLASTIC BALL HANDLES
1
54
K-B190
FRU-K3-PINION SHAFT HUB HANDLE
1
55
K-B148
FRU-K3-QUILL LOCK SLEEVE ASSY
1
56
K-B148-1
FRU-K3-COMPRESSION SPRING
1
57
20836
SPINDLE ASSY
1
58
KB-201
FRU-K3-INDICATOR ROD SCREW
1
59
20845
FRU-K3-LOCK HANDLE ASSY
1
60
KB-202
FRU-K3-INDICATOR ROD
1
61
K-B164
FRU-K3-QUILL STOP MICRO-SCREW
1
62
K-B160
FRU-K3-SNAP RING Ø16
1
63
K-B124-2
FRU-K3-FEED TRIP PLUNGER NUT M40-P0.7
2
64
K-B124-1
FRU-K3-FEED TRIP PLUNGER SOC SET SCREW M4-P0.7x20L
1
65
K-B145
FRU-K3-FEED TRIP LEVER
1
66
K-B124
FRU-K3-FEED TRIP PLUNGER
1
67
K-B185
FRU-K3-REVERSE TRIP BALL LEVER SCREW
1
68
K-B144
FRU-K3-SOCKET SET SCREW
1
69
K-B183
FRU-K3-REVERSE TRIP BALL LEVER
1
70
K-B161
FRU-K3-QUILL MICRO-STOP NUT
1
71
K-B162
FRU-K3-MICROMETER NUT
1
72
K-B123
FRU-K3-TRIP PLUNGER BUSHING
1
73
K-B184
FRU-K3-FEED REVERSE TRIP PLUNGER
1
74
K-B121
FRU-K3-TRIP PLUNGER
1
75
K-B120
FRU-K3-COMPRESSION SPRING
1
76
K-B158
FRU-K3-CHEM BLACKED RD.HD.SCREWS (2 REQ.) M5-P0.8x8L
2
77
K-B118
FRU-K3-CAM ROD SLEEVE ASSY
1
78
K-B159
FRU-K3-MICROMETER SCALE
1
79
KB-200
FRU-K3-SCREW- SOC HD 3/8-24NFx15L
1
80
K-B163
FRU-K3-QUILL STOP KNOB
1
81
20779-5
FRU-SK2/SK3-FEED REVERSE CLUTCH SUB-ASSY (3VK-B5)
1
82
OIL-1
FRU-K3-OIL CUP
1
83
K-B109
FRU-K3-KEY 3x3x20L
1
84
K-B17-1
FRU-K3-WORM GEAR SET SCREW M6-P1.0x8L
1
85
K-B88-1
FRU-K3-COMPRESSION SPRING
1
86
K-B89
FRU-K3-OVERLOAD CLUTCH LEVER SPRING PLUNGER
1
87
20779-3
FRU-SK2/SK3-QUILL PINION SUB-ASSY (3VK-B3)
1
88
K-B167
FRU-K3-KEY 5x5x25L
1
89
K-B27-1
FRU-K3-SET SCREW M6-P1.0x8L
1
90
K-B41
FRU-K3-NEEDLE BEARING BA66 BEARING SIZE KO-BA66Z
1
91
K-B192
FRU-K3-QUILL HOUSING
1
92
K-B104
FRU-K3-TRIP HANDLE
1
93
K-B105
FRU-K3-BLACK PLASTIC BALL
1
94
K-B125-1
FRU-K3-HANDWHEEL SPRING PIN Ø3x3x10L
1
95
K-B125
FRU-K3-HANDWHEEL
1
96
K-B111
FRU-K3-REVERSE KNOB
1
97
K-B100
FRU-K3-CAP SET SCREW M5-P0.8x35L
3
98
20832
FEED TRIP ASSY
1
99
20835
HANDWHEEL ASSY
1
100
20849
HANDLE - FEEDS HANDLE ASSY
1
101
20847
MICRO SCREW, MICRO-STOP NUT &MICROMETER NUT ASSY
1
102
24051
CLOCK SPRING
1
103
24052
TRIP HANDLE ASSY
1
i00699-K2-K3
