XYZ Machine Tools SMX 5000 User Manual

149
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 3500 Lower Head Assembly (Figures 62)
ITEM
P/N
DESCRIPTION
QTY
1
732-3
DRAWBAR
1
2
897
OIL CUP
1
3
J-053
PINION SHAFT HUB SLEEVE
1
4
F-061
QUILL PINION OVERLOAD CLUTCH LOCKNUT
1
5
J-321
SAFETY CLUTCH SPRING
1
6
J-058
OVERLOAD CLUTCH
1
7
J-054
OVERLOAD CLUTCH SLEEVE
1
8
J-051
SPRING PLUNGER
1
9
J-062-3
QUILL PINION SHAFT BUSHING
1
10
J-061-3
PINION SHAFT WORM GEAR SPACER
1
11
J-060-3
OVERLOAD CLUTCH WORM GEAR
1
12
J-059
OVERLOAD CLUTCH RING
1
13
J-010-3
OVERLOAD CLUTCH TRIP LEVER
1
14
J-052
OVERLOAD CLUTCH WASHER
1
15
J-018
CLUTCH ARM COVER
1
16
J-048-3
CAM ROD
1
17
J-017
FEED TRIP BRACKET
1
18
J-047-3
CAM ROD SLEEVE ASSEMBLY
1
19
J-045
TRIP PLUNGER
1
20
J-166-B
DRIVING BLOCK
2
21
J-166-3
SPINDLE
1
22
J-272-3
LOCK NUT
1
23
J-172-3
NOSEPIECE
1
24
J-169-3
SPINDLE DIRT SHIELD
1
25
J-170-3
BEARING SPACER(LARGE)
1
26
J-171-3
BEARING SPACER(SMALL)
1
27
J-167
QUILL
1
28
J-270-3
STELL PLATE
2
29
J-155-3
T-BOLT
4
30
J-094-3
SPACER
2
31
J-355-3
HEX NUT
4
32
J-091-3
WASHER
4
33
J-157
QUILL MICRO STOP NUT
1
34
J-038
MICROMETER NUT
1
35
J-036-3
QUILL STOP KNOB
1
36
J-037
QUILL STOP MICRO SCREW
1
37
J-063-3
QUILL PINION SHAFT
4
38
J-148
PINION SHAFT HUB SCREW
1
39
J-055-3
PINION SHAFT HUB
1
40
M-036
PINION SHAFT HUB SLEEVE
1
