XYZ Machine Tools SMX 5000 User Manual

150
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
ITEM
P/N
DESCRIPTION
QTY
41
J-016-3
SPRING COVER
1
42
J-328-3
CLOCK SPRING
1
43
J-039
REVERSE TRIP BALL LEVER
1
44
J-140
WORM GEAR
1
45
J-141-3
WORM SHAFT
1
46
J-001-3
QUILL HOUSING
1
47
J-333-3
PLASTIC BALL
1
48
J-256
COMPRESSION SPRING
1
49
J-330
50
J-128-3
QUILL SKIRT
1
51
J-310
STEEL BALL
1
52
J-346-3
SPINDLE BEARING “FAFNIR” “2MM210WIDUL”
2
53
J-349-3
BEARING 6210ZZ
1
54
J-019
KEY
1
55
J-142
KEY
1
56
J-057
KEY
1
57
J-154
CLUTCH RING PIN
1
58
J-260
DOWEL PIN
1
59
J-281
PIN
1
60
J-282
PIN
1
61
J-273-3
RING
1
62
J-288
SNAP SPRING
1
63
J-319
SNAP RING
1
64
J-024
MICRO SCREW JAM NUT
2
65
J-269
NUT
1
66
J-289-3
QUILL HANDLE LOCK NUT
1
67
J-356
NUT
2
68
M89
CLOCK SPRING STUD
1
69
J-163
SET SCREW
1
70
J-276-3
SCREW
2
71
J-143
SOCKET SET SCREW
1
72
J-350
LOCKSCREW
1
73
J-264
CAP SCREW
2
74
J-268
SOCKET SET SCREW
1
75
J-275
SOCKET SET SCREW
1
76
J-313
SCREW
1
77
J-356-5
SET SCREW
1
78
J-278
SCREW
1
