XYZ Machine Tools SMX 5000 User Manual

34
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Also, check the wiring connection between the Flash Drive and
the Mother Board. See Computer/Pendant diagnostics Section
4.3.
Computer/Pendant has failed
See Computer/Pendant diagnostics Section 4.3.
3.3.7 System Reboots by Itself
During operation, the screen suddenly blanks and then shows that the system has begun the boot-up
sequence.
Possible Cause
Check This
Interruption of 110 V power to
pendant
Using a Voltmeter, check the incoming 110VAC to the pendant.
Poor wiring and cable connections
Check for any loose wiring or cables
Computer/Pendant failed
See Computer/Pendant diagnostics Section 4.3
3.3.8 System Shuts Off
During operation, the system shuts off and will not turn back on.
Possible Cause
Check This
Fuse blown in pendant
Remove fuse and check continuity
Poor wiring and cable connections
Check for any loose wiring.
Transformer output
Check 110 V Transformer output
Computer/Pendant has failed
See Computer/Pendant diagnostics Section 4.3.
3.3.9 Will Not Hold Calibration
The control will not hold calibration. Go to the "Configuration Values" screen and write down the
calibration values for the motor encoders (Encoder) and the position feedback encoders (Scales). The
calibration values are written in Hexadecimal. Recalibrate the system and see if the values change. Turn
the system off and on and see if the values are held.
Do the following service codes and procedures:
 Code 33 Software Identification. This is needed if you call Customer Service.
 Code 313 Configuration Values
 Code 123 Calibration Mode
Possible Cause
Check This
Configuration file corrupt
Load default configuration by going to code 313
Not saving Calibration values
Replace Computer/Pendant module.
If calibration factors are being saved, but the measurements are not repeating or are not accurate:
 See Measurements Are Not Repeating
 See Measurements Are Not Accurate
3.3.10 Auxiliary Functions Not Working
The Auxiliary Functions will not turn on or off at the programmed times. There are 3 Auxiliary Functions:
1. Turns coolant pump on or off.
2. Sends an electrical signal to rotate the turret on an indexer.
3. Turns the "Spindle Off" at the end of a programmed event.
In order to run the above auxiliary functions in run mode the accessory key on the front of the pendant
must be in the AUTO mode.
All of the auxiliary function signals are carried down to the cable breakout box through umbilical #2. Each
function then has its own relay inside this box. If one of these relays fail then these features will not
work.
