XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 3500 - Y Axis Drive Assembly (Figure 20a & b)
ITEM
P/N
DESCRIPTION
QTY
1
H-026
SCREW
1
2
H-026-A
ADJUSTING SCREW
3
3
H-026-B
SCREW
3
4
H-032-3A
ALUMINUM PLATE
1
5
H-034-3
SADDLE
1
6
H-067-10A
MACHINE BASE
1
7
H-075
FIXED HOLDER OF COOLANT NOZZLE
1
8
H-102-8
SCREW
6
9
H-103
ADJUSTING BLOCK
6
10
H-106-3
GIB SEAT
1
11
H-107-3
GIB SEAT
1
12
H-108-3
GIB
2
13
H-165-8
CONNECTION PIPE
1
14
H-166-10
COVER
1
15
H-166-10A
COVER
1
16
H-170-8
WASHER
1
17
H-237-8
COVER
1
18
H-237-10
COVER
1
19
H-239-A
OIL NETWORK
2
20
H-254
OIL NETWORK
5
21
H-258
COOLANT PUMP
1
22
H-259
COOLANT NOZZLE
1
23
H-261-10
UP-DOWN CHIP GUARD
1
24
H-263-10
BRACKET OF UP-DOWN CHIP
1
25
H-264-10
AUTO LUBRICATION PUMP
1
26
H-267-10
TEFLON(L)
1
27
H268-10
TEFLON(R)
1
28
H-280-10
FIXED PLATE (L)
1
29
H-281-10
FIXED PLATE (R)
1
30
H-022-3
CROSS SCREW BRACKET
1
31
HT-028-3C
CROSS FEED BEARING BRACKET
1
32
HT-028-10B
CROSS FEED BEARING BRACKET
1
33
HT-029-10
TABLE
1
34
HT-034-10A
EXTENSION
1
35
16983-1
PULLEY-BALL SCREW
1
37
HT-096-3
COVER
1
38
HT-097-3
COVER
1
39
HT-151
BEARING COVER
1
40
HT-152
NUT
1
41
HT-166
BUSHING
1
42
HX-046
STOP BLOCK OF LIMIT SWITCH
2
