XYZ Machine Tools SMX 5000 User Manual

77
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
ITEM
P/N
DESCRIPTION
QTY
43
HX-054-10D
COVER
1
44
HY-065-8
CROSS DUST GUARD
1
45
HY-066-8
FOOT REST
1
46
HY-066-8A
FOOT REST
1
47
KEY
1
48
KEY
1
49
24428-1
MOTOR
1
50
450-5M-15
BELT
1
51
OIL SEAL
1
52
PIPE: 1/2”
2
53
PIPE: 3/8”
1
54
AB6204
BEARING:6204ZZ
2
55
AKP10628
PIN: dia 6.6×28
2
56
ANI110034
NUT: 3/4”-10NC
6
57
ANI118516
NUT: 5/16”-18NC
6
58
ANI120012
NUT: 1/2”-20NF
1
59
ASI614134
SCREW: ¼“ -20NC – 1 3/4”L
2
60
ASI614158
SCREW: ¼“ -20NC – 1 5/8”L
2
61
ASI61434
SCREW: ¼“ -20NC – 3/4”L
18
62
ASI61458
SCREW: ¼“ -20NC – 5/8”L
18
63
ASI631612
SCREW: 3/16“ -24NC – 1/2”L
4
64
ASI6381
SCREW: 3/8“ -16NC – 1”L
4
65
ASI651612
SCREW: 5/16“ -18NC – 1/2”L
4
66
ASI651634
SCREW: 5/16“ -18NC – 3/4”L
6
67
ASI678312
SCREW: 7/8“ - 9NC – 3 1/2”L
6
68
ASM60510
SCREW: M5 X 0.8 X 10L
13
69
AWIH0112
WASHER: ½“
1
70
AWIH01516
WASHER: 5/16“
6
